➤ Auxiliary harness (H2), 6-pin connector
H2/1
LIGHT BLUE (-) 200mA 2nd UNLOCK OUTPUT
This wire produces a (-) 200mA output for progressive locks in which the driver
door unlocks first and the remaining locks unlock with a second press of the
unlock button.
H2/2
WHITE/BLACK (-) 200mA PROGRAMMABLE AUX 3 OUTPUT
This wire provides 200 mA programmable output whenever the transmitter
button(s) controlling AUX 3 is pressed. This output can be programmed to pro-
vide the following types of outputs:
Validity: Output that sends a signal as long as the transmission is re-•
ceived.
Latched: Output that sends a signal when the AUX channel button is •
pressed and continues until the same button is pressed.
Latched, reset with ignition: Similar to the latched output, this type of output •
turns On the first time the AUX channel button is pressed, and turns Off the
next time the same button is pressed. This type of output additionally stops
and resets whenever the ignition is turned On and then Off.
30 seconds (60, 90) timed: The output sends a continuous signal for 30 •
seconds.
Note: Bitwriter® programs from 1 to 90 seconds.
Satmode,
bank
selector
AUDIO
PWR
12
REWFF
PLAY/PROG NR
3456
DISC- DISC+
11:53
XM1-1 CH-001
CH
VOL
SCAN
SOUND
AM/FM
CD/AUX
SAT
RADIO
SEEK
SKIP
RPT
DISP -
MODE
A.SEL
RDM
TUNE
AUTO
OFF
DUAL
A/C
MODE
Channel control
Category
Control
Text selector.
Hold for 10secto toggle
channelor category
tune
modes.
Toggles
Scan
mode
Bank and
present
indicator
Channel
and text
indicator
Preset 1-6.
Hold until beepto
savetoapreset.
CATEGORY
Tune mode
indicator
MODE
DUAL
OFF
AUTO
MAP/
GUIDE
MENU
SETUP
INFO
ZOOM
CANCEL
AUDIO
AUTO
MODE
A/C
LOAD
DISC
TAPE
AM/FM
DISP
MODE
SCAN RPT A.SEL/RDM-SEEK +
1
2
34
5
6
DISC-
DISC+
VOL
PWR
PUSH
TUNE
SOUND
PUSH
XM1-1
VOL
CH
CHANNEL
CATEGORY
NAME
TITLE
:
:
:
:
1
CH
2
CH
3
CH
6
CH
5
CH
4
CH
MODE SCAN SOUND
001-HITS1
POP
MUSICNAME
MUSIC TITLE
Channel control
Category
Control
001 014 018
040 065
115
Toggles between
channel and
category
modes
Bank and
present
indicator
Upper display
text mode
selector
Sat mode
and bank
selector
Preset 1-6.
Press until
beepto save
to a preset.
Channeland text
Indicator
fields
Toggles
Scan
mode
Tune mode
indicator
ANTENNA
SC OUTPUT
Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda Bus Compatible Translator
Headunit bus cableSiriusConnect Cable
HON-SC1
Honda Bus
Compatible
Translator
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied out-
put is only 200mA. Connecting directly to a
solenoid, motor, or other high-current device
will cause the module to fail.
