H3/5
BLUE/WHITE (-) 200mA STATUS OUTPUT / REAR DEFOGGER
This wire supplies a 200mA output as soon as the module begins the remote
start process. The Blue/White wire can also be used to activate the defogger
trigger (latched/pulsed), 10-seconds after the remote start engages.
(See the Feature Descriptions section in this guide for details about programming
this output.)
➤ AUX 4, Horn, (H4) 2-pin connector
H4/1
ORANGE/BLACK (-) 200 mA PROGRAMMABLE AUX 4 OUTPUT
This wire provides a (-) 200mA output whenever the transmitter button(s) control-
ling AUX 4 is pressed. (see also the Feature Descriptions section and previous
AUX 3 description)
Satmode,
bank
selector
AUDIO
PWR
12
REWFF
PLAY/PROG NR
3456
DISC- DISC+
11:53
XM1-1 CH-001
CH
VOL
SCAN
SOUND
AM/FM
CD/AUX
SAT
RADIO
SEEK
SKIP
RPT
DISP -
MODE
A.SEL
RDM
TUNE
AUTO
OFF
DUAL
A/C
MODE
Channel control
Category
Control
Text selector.
Hold for 10secto toggle
channelor category
tune
modes.
Toggles
Scan
mode
Bank and
present
indicator
Channel
and text
indicator
Preset 1-6.
Hold until beepto
savetoapreset.
CATEGORY
Tune mode
indicator
MODE
DUAL
OFF
AUTO
MAP/
GUIDE
MENU
SETUP
INFO
ZOOM
CANCEL
AUDIO
AUTO
MODE
A/C
LOAD
DISC
TAPE
AM/FM
DISP
MODE
SCAN RPT A.SEL/RDM-SEEK +
1
2
34
5
6
DISC-
DISC+
VOL
PWR
PUSH
TUNE
SOUND
PUSH
XM1-1
VOL
CH
CHANNEL
CATEGORY
NAME
TITLE
:
:
:
:
1
CH
2
CH
3
CH
6
CH
5
CH
4
CH
MODE SCAN SOUND
001-HITS1
POP
MUSICNAME
MUSIC TITLE
Channel control
Category
Control
001 014 018
040 065
115
Toggles between
channel and
category
modes
Bank and
present
indicator
Upper display
text mode
selector
Sat mode
and bank
selector
Preset 1-6.
Press until
beepto save
to a preset.
Channeland text
Indicator
fields
Toggles
Scan
mode
Tune mode
indicator
ANTENNA
SC OUTPUT
Sirius-Ready, SAT Radio Ready or select OEM headunits with optional Honda Bus Compatible Translator
Headunit bus cableSiriusConnect Cable
HON-SC1
Honda Bus
Compatible
Translator
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied out-
put is only 200mA. Connecting directly to a
solenoid, motor, or other high-current device
will cause the module to fail.
H4/2
BROWN (-) 200mA HORN HONK OUTPUT
This wire provides a (-) 200mA output to the horn. It can be programmed to
activate when the system is triggered or when the siren sounds (while arming,
disarming, warn away and full trigger). See menu 1 for programming.
