➤ Relay satellite 4-pin connector
H/1
BLUE (-) 200mA STATUS OUTPUT
This wire supplies a 200mA output when remote start process begins.
H/2
ORANGE (-) 200mA ACCESSORY RELAY TURN ON
The wire supplies a (-) 200mA output and controls up to two additional relays.
Connect this wire to power additional accessory wires.
H/3
PURPLE (-) 200mA STARTER RELAY TURN ON
The wire supplies a (-) 200mA output and controls up to two additional relays.
Connect this wire to power additional starter wires.
H/4
PINK (-) 200mA IGNITION RELAY TURN ON
The wire supplies a (-) 200mA output and controls up to two additional relays.
Connect this wire to power additional ignition wires.
➤ Remote start, (H3) secondary harness
H3/1
BLACK/WHITE NEUTRAL SAFETY SWITCH INPUT
Connect this wire to the provided toggle (override) switch as shown in figure
A. Connect the other wire from the toggle switch to the park/neutral switch in
the vehicle. This wire will test with ground with the gear selector either in PARK
or NEUTRAL. This will prevent the vehicle from accidentally being started while
in a drive gear. This input MUST rest at ground in order for the remote start
system to operate. Connected properly the vehicle will only start while in PARK
or NEUTRAL.
In some vehicles, the park/neutral position switch activates a factory starter lock
out that will not allow the starter to operate in a drive gear. In these vehicles,
connect this wire to the toggle switch as shown in figure B. Connect the other
wire from the toggle switch to chassis ground.
