RED (2) (+) 12V INPUT FOR HIGH CURRENT OUTPUTS
Remove the two 30-amp fuses prior to connecting these wires and do not re-
place them until the harness has been plugged into the control module. These
wires are the source of current for pink ignition, orange accessory, purple starter,
and the coils for the relays in the relay pack. They must be connected to a high
current source. Since the factory supplies (+)12V to the key switch that is used to
operate the motor, it is recommended that these wires be connected there.
Note: If the factory supplies two separate (+) 12V feeds to the ignition switch,
connect one RED wire of the satellite to each feed at the switch.
H/4
ORANGE (+) ACCESSORY OUTPUT
Connect this wire to the accessory wire in the vehicle which powers the climate
control system.
H/5
PINK (+) IGNITION OUTPUT
Connect this wire to the ignition wire in the vehicle.
H/6
PINK/WHITE (+) SECOND IGNITION ACCESSORY OUTPUT-PROGRAMMABLE
Connect this wire to the second ignition/accessory wire in the vehicle. (See
menu feature 3-6.)
Note: For vehicles that do not have a second ignition/accessory wire, this
connection is not required.
H/7
RED/WHITE (+) 12V INPUT
Connect this wire to a +12V source. It supplies voltage to the pink/white 2nd
ignition/accessory output. If the vehicle does not have a 2nd ignition/acces-
sory, then this wire does not need to be connected.
