14
© 2009 Directed Electronics. All rights reserved.
➤ Remote start ribbon harness
1
PINK/WHITE (-) 200mA PROGRAMMABLE IGN2/ACC2 RELAY TURN ON
2
YELLOW (+) IGNITION INPUT TO ALARM
3
PINK (-) 200mA IGNITION RELAY TURN ON
4
ORANGE (-) 200mA ACCESSORY RELAY TURN ON
5
PURPLE (-) 200mA STARTER RELAY TURN ON
6
ORANGE/BLACK (-) 500mA ANTI GRIND/GROUND WHEN ARMED OUTPUT
7
BLUE (-) 200 mA STATUS OUTPUT
The ribbon harness connects to the heavy gauge relay satellite.
➤ Heavy gauge relay satellite
H/1
PURPLE STARTER OUTPUT TO STARTER (STARTER SIDE)
H/2
GREEN STARTER INPUT FROM IGNITION (KEY SIDE)
H/3
RED (+) 30A HIGH CURRENT 12V INPUT
H/4
ORANGE OUTPUT TO ACCESSORY CIRCUIT
H/5
PINK OUTPUT TO PRIMARY IGNITION CIRCUIT
H/6
RED (+) (30A) HIGH CURRENT 12V INPUT
H/7
PINK/WHITE OUTPUT TO SECOND IGNITION CIRCUIT
H/8
RED/WHITE (+) (30A) HIGH CURRENT 12V INPUT
➤ Relay satellite 4-pin connector
1
BLUE (-) 200mA STATUS OUTPUT
2
ORANGE (-) 200mA ACCESSORY RELAY TURN ON
3
PURPLE (-) 200mA STARTER RELAY TURN ON
4
PINK (-) 200mA IGNITION RELAY TURN ON
