➤ Primary harness (H1), 12-pin connector
H1/1
RED/WHITE (-) 200mA AUX TRUNK RELEASE OUTPUT
H1/2
RED (+) CONSTANT POWER INPUT
H1/3
BROWN (+) SIREN OUTPUT
H1/4
EMPTY NOT USED
H1/5
BLACK (-) CHASSIS GROUND INPUT
H1/6
VIOLET (+) DOOR TRIGGER INPUT, ZONE 3
H1/7
BLUE (-) TRUNK PIN/INSTANT TRIGGER, ZONE 1
H1/8
GREEN (-) DOOR TRIGGER INPUT, ZONE 3
H1/9
BLACK/WHITE (-) 200mA DOMELIGHT SUPERVISION OUTPUT
H1/10
WHITE/BLUE (-) REMOTE START ACTIVATION INPUT
H1/11
WHITE (+)/(-) SELECTABLE LIGHT FLASH OUTPUT
H1/12
ORANGE (-) 500mA GROUND WHEN ARMED OUTPUT
➤ Auxiliary harness (H2), 6-pin connector
H2/1
LIGHT BLUE (-) 200mA SECOND UNLOCK OUTPUT
H2/2
WHITE/BLACK (-) 200mA AUX 3 OUTPUT
H2/3
VIOLET/BLACK (-) 200mA AUX 2 OUTPUT
H2/4
GREEN/WHITE (-) 200mA FACTORY ALARM REARM OUTPUT
H2/5
GRAY/BLACK (-) WAIT-TO-START INPUT
H2/6
LIGHT GREEN/
BLACK
(-) 200mA FACTORY ALARM DISARM OUTPUT
➤ Door lock harness, 3-pin connector
1
LIGHT BLUE (-) UNLOCK (+) LOCK OUTPUT
2
EMPTY NOT USED
3
GREEN (-) LOCK (+) UNLOCK OUTPUT
