Directed DBALL User Manual

The optional XL202 and antenna are not included and MUST be purchased separately.
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
4
4
XL202
Antenna
XOVER
SmartStart is optional and not included. It MUST be purchased separately.
SmartStart is optional and not included. It MUST be purchased separately.
The DBALL Remote Start Ready (RSR) solution offers three (3) configuration options to control your system; 3x OEM Lock
Remote Start Activation, XpressStart Kit or SmartStart (all sold separately). This section provides specific installation
information for SmartStart and XL202.
Configuration Wires (Gray & White)
Connect Gray wire to (-) Ground
5 pins
D2D (4 pins, white)
4 pins
2 pins,
not used
CABLE
CABLE
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
1. Use the D2D Crossover (XOVER) cable that is provided with XL202, and NOT the one in the DBALL package.
2. The modules must be connected in a specific order. Refer to the Module Programming section for more information.
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
SmartStart/XL202 Installation Notes
SmartStart Revision B
XpressStart Kit
XpressStart Kit & PKE Combination
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
XpressStart Kit, PKE & SmartStart BT Combination
SmartStart Revision A
DBALL/
DBALL2
DBALL/
DBALL2
DBALL/
DBALL2
LED
Prog.
Button
D2D (4 pins, white)
4 pins
2 pins,
not used
OR
SmartStart
Configuration Wires (White & Brown or Blue)
Cut Brown or Blue Loop
LED
THIS SIDE UP
LED
Page 10
Rev.: 20140916
Platform: DBALL/DBALL2
Firmware: GM9 Remote Start Ready (RSR) Installation
© 2014 Directed. All rights reserved.
