D2D and W2W Commands
Flashes orange x
1
LOCK command received.
Normal operation. If the LED do not flash, it means the
module did not receive the signal. Commands can come
from RF, D2D or W2W.
Flashes orange x
2
UNLOCK command received.
Flashes orange x
3
TRUNK command received.
Flashes orange x
4
AUX1 command received.
Remote Start Shutdown Code
Flashes red x 1 Run safe shutdown.
Flashes red x 2 Brake shutdown.
Flashes red x 3 No key detected shutdown.
Flashes red x 4 Speed detected.
Flashes red x 5 Start fail.
Flashes red x 6 Stop fail.
Flashes red x 7 RFTD disabled
3x OEM Lock Remote Start Activation was attempted
when RFTD feature is disabled. Activated from Web
automatically when using RXT flash tool or can be done
manually. Refer to feature programing section for more
information.
Flashes red x 8 OEM RS disabled.
RXT start not possible when OEM system is disabled.
Refer to the owner documentation to activate it.
Used to check the installation and for troubleshooting
purposes. Used to check for internal safety operation.
Does not represent an error.
RXT start command not executed. Module received the
command, but the car did not perform the action.
Flashes
orange
x2
Flashes
red x2
Flashes
red x5
Flashes
orange
x3
Flashes
red x3
Flashes
red x6
Flashes
orange
x4
Flashes
red x4
Flashes
red x7
Flashes
red x8
Flashes
orange
x1
Flashes
red x1
Flashes Diagnostic
1 Runtime expired.
2 Over-rev shutdown.
3 Low/No RPM.
4 Transmitter shutdown.
5 Brake shutdown.
6 Hood shutdown/Remote start safety override switch is ON*.
7 Remote start safety override switch is ON*.
The parking lights on your vehicle will flash a specific number of times 3 seconds following an unscheduled shutdown or
failure to start. Each flashing pattern is described below.
* If the vehicle hood status is supported through data, safety override switch input will report 7 flashes.
Parking Light Error Codes
