Directed DBALL User Manual

Rev.: 20140916
Platform: DBALL/DBALL2
Firmware: GM9 Remote Start Ready (RSR) Installation
© 2014 Directed. All rights reserved.
Vehicle Wiring Reference Chart - Type 1 (continued)
Page 7
Function
Color Pin Polarity Location Color No. Pin
SW Can Green 22 Data BCM under driver dash Blue 27 Pin
Can H Blue 24 Data BCM under driver dash Blue 27 Pin
Can L White 23 Data BCM under driver dash Blue 27 Pin
PTS Blue 17 Resistor BCM under driver dash Blue 27 Pin
Brake Output Blue/Yellow 7 Resistor BCM under driver dash Blue 27 Pin
Brake 5V Reference Input White 13 Positive BCM under driver dash Blue 27 Pin
Immo. Data Green/Violet 2 Data BCM under driver dash Green 25 Pin
Parking Lights Green/Gray 22 Negative BCM under driver dash White 26 Pin
Horn Brown/White 19 Negative BCM under driver dash Brown 26 Pin
(+) 12V
Red/Violet
4 Positive BCM under driver dash Blue 27 pin
SW Can Green 22 Data BCM under driver dash Blue 27 Pin
Can H Blue 24 Data BCM under driver dash Blue 27 Pin
Can L White 23 Data BCM under driver dash Blue 27 Pin
PTS Green 17 Resistor BCM under driver dash Blue 27 Pin
Brake Output Blue 7 Resistor BCM under driver dash Blue 27 Pin
Brake 5V Reference Input White 13 Positive BCM under driver dash Blue 27 Pin
Immo. Data Green/Violet 2 Data BCM under driver dash Green 25 Pin
Parking Lights Gray 22 Negative BCM under driver dash White 26 Pin
Horn Brown/White 19 Negative BCM under driver dash Brown 26 Pin
(+) 12V
Red/Violet
4 Positive BCM under driver dash Blue 27 Pin
Chevrolet Malibu
Push-to-Start
2013-2014
Chevrolet Impala
Push-to-Start
2014
Wire Information Connector Information
Vehicle
