Directed DS4 Plus

10
DS4+ VW10
© 2017-11-02 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Volkswagen Jetta SportWagen 2011-2014
Parking Light Gray/Yellow 3 (+) Headlight Switch. Black 10 A
Parking Light Interrupt Red/White 8 Cut Headlight Switch. Black 10 A
Starter Red/Brown or Red/Black 6 (+) Steering column module. Black 16 B
Ignition Black 14 (+) Steering column module. Black 16 B
FT CAN High Orange/Green 4 Data Steering column module. Black 16 B
FT CAN Low Orange/Brown 3 Data Steering column module. Black 16 B
HS CAN High Orange/Black 6 Data OBDII. Violet/Black 16 C
HS CAN Low Orange/Brown 14 Data OBDII. Violet/Black 16 C
12V Red /Yellow 42 (+) VESCM connector C, under drivers dash. Brown 52 D
Brake Black/Red 17 (+) VESCM connector C, under drivers dash. Brown 52 D
Volkswagen Tiguan 2010-2016
Parking Light Gray/Yellow 3 (+) Headlight switch. Black 10 A
Parking Light Interrupt Red/Blue 8 Cut Headlight switch. Black 10 A
Ignition Black 14 (+) Steering column module behind steering column trim. Black 16 B
Starter Red/White or Red/Black 6 (+) Steering column module behind steering column trim. Black 16 B
FT CAN High Orange/Green 4 Data Steering column module behind steering column trim. Black 16 B
FT CAN Low Orange/Brown 3 Data Steering column module behind steering column trim. Black 16 B
HS CAN High Orange/Black 6 Data OBDII. Violet/Black 16 C
HS CAN Low Orange/Brown 14 Data OBDII. Violet/Black 16 C
12V Red/Violet 42 (+) VESCM connector C, under drivers dash. Brown 52 D
Brake Black/Red 17 (+) VESCM connector C, under drivers dash. Brown 52 D
