Wiring connections
The wiring connections listed below are specific to this firmware.
Main harness (H1), 12-pin black connector
Conn./Pin Color Description
H1/1 Blue/White Relay 1 N.C. – Parking Light Interrupt (conn. side)
1
H1/2 Blue/Red Relay 1 N.O. – (+) Parking Light Output or (+)12V Input
1
H1/3 Blue Relay 1 COM – (+) Parking Light Interrupt (vehicle side)
1
H1/4 White/Brown Relay 3 N.C. – No Connection
1
H1/5 White Relay 3 COM – (+) Accessory Output
1
H1/6 Red (+) 12 Volt (Input)
H1/7 Lt. Green/Red Relay 2 N.O. – Key Wrap
1
H1/8 Lt. Green Relay 2 COM – Key Wrap
1
H1/9 Lt. Green/White Relay 2 N.C. – Key Wrap
1
H1/10 Black (-) Ground
H1/11 White Relay 3 COM – (+) Accessory Output
1
H1/12 Red (+) 12 Volt (Input)
Relay harness (H2), 10-pin white connector
Conn./Pin Color Description
H2/1
N/A No Connection
H2/2
Red/Black No Connection
H2/3
Pink/Black No Connection
H2/4
Pink/White No Connection
H2/5
Red No Connection
H2/6
Green No Connection
H2/7
Violet No Connection
H2/8 Orange No Connection
H2/9
Red/White No Connection
H2/10
Pink No Connection
Data harness (H3), 8-pin white connector
Conn./Pin Color Description
H3/1 Tan HS CAN Low
H3/2 Tan/Black HS CAN High
H3/3 Orange/Brown FT CAN Low
H3/4 Orange/Green FT CAN High
H3/5 Lt. Green No Connection
H3/6 Violet/Brown (MUX) Lock/Unlock Output
H3/7 Orange/Black ISO BUS 2
H3/8 Yellow/Black ISO BUS 1
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
