DS4+ VW10
© 2017-11-02 Directed. All rights reserved.
Type 9
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
Siren
Hood Pin
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
(+) Starter Output: White: 7
(+) Ignition Output: Violet/Black: 8
FT CAN High: Orange/Green: 4
FT CAN Low: Orange/Brown: 3
(+) 12V Input: Red: 6 & 12
Key Wrap: Lt.Green/Red: 7
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
(+)12V: Pin 1
VESCM Connector L
(under drivers dash or behind glove box)
22
10
4
1
6
3
F
H
GE
VESCM
(under drivers dash or below glove box)
(+) Starter: Pin 1
6542 31
12
11
10
87
G plug
at VESCM
(under drivers dash
or below glove box)
9
(+) Ignition: Black or Black/Green, pin 11
FT CAN Low:
Orange/ Brown,pin 7
FT CAN High:
Orange/Green, pin 8
16
8
9
1
HS CAN Low: Tan : 1
HS CAN High: Tan/Black: 2
HS CAN High: Orange/Black, pin 6
HS CAN Low: Orange/Brown, pin 14
Parking Lights Interrupt: Red/White, pin 8
(+) Parking Lights:
Gray/Yellow, pin 3
1
2
4
5
6
7
9
10
3
8
CUT
Headlight switch
(black conn. at
light switch)
Parking Light Interrupt (conn. side): Blue/White: 1
2
1
(+) Parking Light Output: Blue/Red: 2
Parking Light Interrupt (vehicle side): Blue: 3
Diagnostic
Connector
OBDII
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
