7
DS4+ VW10
© 2017-11-02 Directed. All rights reserved.
Analog input/output harness (H4), 22-pin white connector
Conn./Pin Color Description
H4/1 Lt. Green/Black (-) Hazards Output
1
H4/2 Blue/White (-) Key Release Output
1
H4/3 Dk. Green/Black (-) Lock Output
1
H4/4 Red/White (-) Trunk Release Output
1
H4/5 Brown/Black (-) Horn Output
1
H4/6 Brown/White N/A
H4/7 White (+) Starter Output
1
H4/8 Violet/Black (+) Ignition Output
1
H4/9 Dk. Blue/Black (-) Unlock Output
1
H4/10 Lt. Blue/Black (-) FAD Output
1
H4/11 Brown/Red (+) Siren Output
1
H4/12 Pink (+) Ignition Sense Input
H4/13 Violet (+) Door Sense Input
2
H4/14 Brown (+) Brake Input
2
H4/15 White/Blue (-) Activation Input
2
H4/16 Blue/Red (-) Valet Switch
2
H4/17 Black/White (-) E-Brake Input
2
H4/18 Orange/Black (-) Instant Alarm Trigger Input
2
H4/19 Blue (-) Trunk Sense Input
2
H4/20 Green (-) Door Sense Input
2
H4/21 Gray (-) Hood Pin Input
2
H4/22 Violet/White (AC) Tach Input
RF Port harness (H5), 2-pin white connector
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness (H6), 4-pin white (1) and black (2) connectors
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
Temperature sensor harness (H7), 2-pin black connector
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they
are low current and a relay may be necessary.
