Directed XpressKit User Manual

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Vehicle Application Guide
Page 2
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
Vehicles
2017
2016
2015
2014
2013
2012
PK-Immobilizer Bypas s-Data No Key Req'd
DL-Arm Factory Security
DL-Disarm Factory Security
DL-Door Lock Control
DL-Door Unlock
DL-Driver Priority Unlock
DL-Trunk / Hatch Release
FOB-Control of aftermarket alarm with OEM
remote
RS-SmartStart
RS-Tach / RPM Output
SS-Entry Monitoring ALL Door Pins
SS-Entry Monitoring Hood Pin
SS-Entry Monitoring Trunk/Hatch Pin
SS-Factory Alarm Trigger Monitoring
ST-Brake Status (foot brake)
ST-Door Locks Status
ST-E-Brake Status
ST-Ignition Status
Lexus
ES 300h (Smart Key) 3 3 3 • • • • • • • D D ••••D•D••
ES350(SmartKey) 111 •••••••DD••••D•D••
GS350(SmartKey) 8222 • • • • • • • D D ••••D•D••
GS450h(SmartKey) 222 •••••••DD••••D•D••
Toyota
Avalon(SmartKey) 6444 • • • • • • • D D ••••D•D••
AvalonHybrid 6444 • • • • • • • D D ••••D•D••
Camry(SmartKey) 664444 • • • • • • • D D ••••D•D••
CamryHybrid 664444 • • • • • • • D D ••••D•D••
Corolla(SmartKey) 6555 • • • • • • • D D ••••D•D••
Priusc(SmartKey) 444•••••••DD••••D•D••
RAV4(SmartKey) 66444 • • • • • • • D D ••••D•D••
RAV4Hybrid 77 •••••••DD••••D•D••
Notes:
• Keyless and Smart Key will remain functional during remote start.
* By default, the tach is set to 1000 rpm on hybrid vehicles.
Legend:
PK: Transponder & Immobilizer Override
D: Data-to-Data (D2D) only
DL: OE Door Lock & Alarm Controls • : D2D & Wire-to-Wire (W2W)
FOB: Sync CAN Interface w/ FOB Remote
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
If the vehicle is already equipped with an OEM remote starter, the installer must
disconnect it before installing the DBALL otherwise it will not program. See how to
know if the vehicle is equipped with an OEM Remote starter on the next page.
