32
Dirtywave M8 Operation Manual
MIDI Settings View
MIDI SETTINGS
RECEIVE SYNC OFF
RECEIVE TRANSPORT ON
SEND SYNC OFF
SEND TRANSPORT ON
REC. NOTE CHAN 09
REC. VELOCITY OFF
REC. DELAY/KILL OFF
CONTROL MAP CHAN 10
SONG ROW CUE CHAN 11
TRACK MIDI INPUT
12345678
CHAN. 01 02 03 04 05 06 07 08
INST# 00 00 00 00 00 00 00 00
PG CHANGE ON LEGATO MODE ON
SAVE DEFAULTS LOAD DEFAULTS
T>120
1 ---
2 ---
3 ---
4 ---
5 ---
6 ---
7 ---
8 ---
P
SCPIT
M
The MIDI settings view is accessible from the project view. Edit the MIDI settings for
sync input and output, transport control (play, stop, continue), MIDI note recording op-
tions, and MIDI channel assignments. All parameters in this page are stored within the
song. Save or load the default conguration used when creating a new song.
MIDI Settings
• RECEIVE SYNC - Enable the song to be synced from an external MIDI clock.
• RECEIVE TRANSPORT - Enable song start/stop controlled from MIDI transport mes-
sages. “PATTERN” will start the song where you last played the song from. “SONG”
will respond to “MIDI song position pointer” messages.
• SEND SYNC - Enable sending MIDI clock messages.
• SEND TRANSPORT - Enable sending song start and stop messages. “PATTERN”
will only send the start and stop messages where as “SONG” will also send a song
position pointer message.
• RECORD NOTE CHANNEL - MIDI channel for recording incoming MIDI notes. See
next section under Recording MIDI Notes.
• RECORD VELOCITY - Enables recording note velocity when recording MIDI notes.
• RECORD DELAY/KILL - Record delay (“DEL”) and kill/note o (“KIL“) FX commands
when recording incoming MIDI notes into a phrase.
• CONTROL MAP CHANNEL - MIDI channel for incoming MIDI CCs for MIDI Map-
ping. Refer to MIDI Mappings View.
• SONG ROW CUE CHANNEL - MIDI channel for incoming MIDI notes for cueing song
rows.
