Dirtywave M8 Operation Manual
MIDI Out
INST. 00
TYPE MIDI OUT LOAD SAVE
NAME ------------
PORT 00MIDI+USB
CHANNEL 001
BANK:PG ---:---
CCA CC:VAL 001:00
CCB CC:VAL ---:--
CCC CC:VAL ---:--
CCD CC:VAL ---:--
CCE CC:VAL ---:--
CCF CC:VAL ---:--
CCG CC:VAL ---:--
CCH CC:VAL ---:--
CCI CC:VAL ---:--
CCJ CC:VAL ---:--
T>120
1 ---
2 ---
3 ---
4 ---
5 ---
6 ---
7 ---
8 ---
P
SCPI T
M
TRANSP. ON
TABLE TIC 01
Control external devices with the MIDI Out instrument either by USB MIDI or the built-in
TRS (type A) MIDI output.
MIDI Out Parameters
• PORT - Set the MIDI Output port: MIDI and USB, MIDI only, or USB only.
• CHANNEL - MIDI Channel selection 1 to 16.
• BANK:PG - Optional MIDI Bank select and Program change. Program change mes-
sages can also be sent as an FX command.
• CC[A-J] CC:VAL - Up to 10 custom MIDI CC numbers with optional default values
can be assigned per MIDI instrument. If a default value is present, it will be sent with
the note on command after program change messages.
