XWEB5000 Operation Manual
3.4.5 GLOBAL COMMANDS FUNCTION
It allows you to place in the layer a command-button and use it to send command to a particular instrument or
to a range of them. We do not describe here again all the functions that are available also in the layout.
3.4.5.1 GLOBAL EDIT
In the homepage, go to Devices and choose “Global Edit”.
Go to insert menu and choose “Global Command”:
Here select the proper category. Once you have
made your choice, the system loads up a new
window.
A summarizing window will appear:
You can check/uncheck manually the instruments or
you can use the Select/Deselect All. Then push
“Continue”
By pushing “Continue” the system makes a check to show you only the compatible commands to the
instruments you have selected.
