Manual de operare Xweb5000
Pag. 81 / 115
green background
not active
ODC
SENT/yellow
command is being sent
ODS
???
unknown state
Act
a digital condition check has
been performed, the result is
true
NotAct
a digital condition check has
been performed, the result is
false
Set
a setpoint condition check has
been performed, the result is
true
NEQ
a setpoint condition check has
been performed, the result is
false
3.5.2 COMPRESSOR RACK OPTIMIZER (C.R.O.) (*
2
)
Dixell, thanks to its ten-year experience in the industrial refrigeration market and even more important, thanks
to the tight relationship with the customer, has developed a specific module intended to energy-saving politics.
C.R.O. basically works with 2 parameters: suction pressure of the compressor rack and the worst case
cabinet. The former is detected via a XC1000D controller (ver.1.1 or higher) by Dixell, the latter is computed
according to a special algorithm based on the time-switching of the solenoid relay.
This propriety algorithm mixes together into a winning software tool the complexity of the refrigeration system
and the easy parameter programming of the user interface. Moreover, once again the software is a JAVA
APPLET, it means no need to install a PC software. Data depends on the seasonal period and varies from
installation to installation. To start the C.R.O., go to “Supervising” then C.R.O. The following windows appears:
To use the C.R.O. you must add a class of . XWEB will extract from this controllers data to calculate the
special algorithm. Go to “Class” menu and create a new class definition..
Open “Operation” menu, the following window appears:
2
(*) Functionality available with 2 motors only with XWEB5000-6AA00
