11
1
1
2
3
3
3
3
4
4
4
4
5
6
8
8
8
8
8
9
10
10
11
12
13
15
13
12
12
12
16
14
14
14
14
14
14
7
9
2
18
17
REF PART# DESCRIPTION Qty
1 68108 3/4”ID X 2-7/8” Long Spacer
2 65047 3/4” Long Bushing
3 S-114 1/2”-13 X 3-1/2” Stud 4
4 N-157 1/2”-13 Whiz Flange Nut 8
5 68105 3/8” Long Bushing
6 68104 #50 10 Tooth Sprocket
7 68106 3/4”ID X 1-3/16” Bushing
8 68103 Deck Lift Sprocket #50 2
9 300353 #50-67P Rear Deck Lift Chain 2
10 68217 #50 Front Deck Lift Chain 2
REF PART# DESCRIPTION Qty
11
11A
990710002
68219
#50-27P Return Spring Chain (74)
Chain - #50 PEDAL LIFT (66)
1
1
12 W-154 3/4” Flat Washer 4
13 B-240 3/4”-9 X 11” Bolt 2
14 10232 #50 Master Link 11
15 N-158 3/4”-9 Nyloc Nut 2
16 68110 3/4” x 34-3/4”Long Shaft
17 300240 Weldment - Arm Sprocket 1
18
18A
300426
300354
Chain - Lift Deck Foot Pedal F/66
Chain - Pedal Foot (74)
1
1
66”, 74” DECK LIFT SYSTEM
11A
18A
To Next Page
