27
XCLP
FUEL LINE ROUTING DIAGRAM
REF PART# DESCRIPTION Qty
600096 Assembly - Hose Propane
1 600108 Fitting - Straight 2
2 600116 Assembly - Hose (34-3/4” Long) 1
3 600110 Tee - 5/8”-18 Thread 1
4 600115 Assembly - Hose (29” Long) 1
5 600107 Fitting - Female 90˚ 1
6 600114 Assembly - Hose (16-1/2” Long) 1
7 400190 Tank - Propane Aluminum 33# 2
8 600117 Coupler - Straight Fitting 2
9 600196 Regulator - Pressure 1
10 026842 Nipple close 1/4” NPT x .875 1
11 0F5913 Filter/Solenoid 1
12 67022 Fitting - 1/4” Street Tee 1
13 0F5912 Valve - High Pressure Relief 1
14 600323 Mount - Valve LP 1
14
