Dixie Chopper XCALIBER 2011 - Damper Installation

18
DAMPER & SEAT BELT INSTALLATION
REF PART# DESCRIPTION Qty
1 200116 Ball Stud 4
2 N-103-W 5/16”-18 Whiz Flange Nut 4
3 200114 Filled Damper AVM P7062 2
4 W-113 5/16” Flat Washer 2
5 B-199 Bolt - 7/16-20X2 HHCS PT Gr.8 Zinc 2
6 N-135 Nut - 7/16 - 20 Nyloc 2
7 900388 Belt - Seat Retractable Classic/Xcaliber 1



 





