Dixie Chopper XCALIBER 2011 - Electrical Diagram

37
PART# DESCRIPTION Qty
500081 Harness - Wiring CL/XC Gas/LP 2010 1
500040 Electric Deck Lift Harness 1
500017 Ignition Switch 1
500018 Key
500037 Hour Meter/Tach 1
400167 Tach Bracket 1
N/A Battery 1
97145 Diesel Battery Tray 1
20228 Battery Strap 1
97323 Battery 2Ga. Cable Positive 80” 1
XCLP GENERAC ELECTRICAL DIAGRAM
A
B
C
A
B
C
RELAY
DC 12V SOCKET
BLACK
BROWN
BLACK
YELLOW
BROWN
YELLOW
BROWN
GREEN
GREEN
Y
E
L
L
O
W
RED
RED
RED
R
E
D
RED
GREEN
BLUE
BLUE
PINK
PINK
WHITE
WHITE
WHITE
YELLOW
BROWN
RED
PINK
BLUE
YELLOW
YELLOW
YELLOW
PURPLE
WHITE
SDJ 8-23-06
500052
Assembly - Harness Generac 33Hp Boomerang Complete
500054 Harness - Generac 33 Hp Boomerang w/o 500053 and 500044
BLACK
BLACK
BLUE
RED
RED
RED
RED
PART# DESCRIPTION Qty
97322 Battery Cable Ground 80”
500062 Clutch Wiring Pigtail 1
500088 Module - Weather Proof Delay 1
500010 Boot - Red Batter Boot f/2 Ga. Wire 1
40229 Mercury Switch 1
C-112 Clamp For Mercury Switch 1
65510 Seat Relay 1
65509 Fuse
20254 Fuse Holder
60117
C-113
Low Oil Horn
Horn Clamp
1
1
200043 Electrical Fan 1
900394 Wrap - Spiral Black 3/4” OD X .065 Thick /ft.
97379 Kit - Light F/Gauges 1
97325 Battery - 551/450 Deka f/Diesel 1
500093 Harness - Regulator Fuel CNG 1
WHITE
GREEN
R
E
D
B
L
A
C
K
(Connect
to Trans.
Frame)
GROUND
FUSE
CONNECT
TO
ACTUATOR
RAISE/LOWER
SWITCH
CONNECT
TO
STARTER
29
500040
NEED CNG WIRING HARNESS
