Dixie Chopper XCALIBER 2011 - Page 35

32
XCLP BODY
REF PART# DESCRIPTION Qty
1 400193 LH Fender Assembly 1
2 400192 RH Fender Assembly 1
3 B-103 1/4”-20x1/2” Stainless Bolt 2
4 W-153 1/4” Stainless Flat Washer 10
5 N-101 1/4”-20 Stainless Whiz Flange Nut 2
6 B-209 1/4”-20X3/4” Stainless Bolt 8
7 B-105 5/16”-18x1.75” Bolt 2
8 W-113 5/16” Flat Washer 6
9 400247 Floor Pan Hinge Bracket 2
10 W-118 5/16”x1.5” Fender Washer 4
12 N-103-W 5/16”-18 Whiz Flange Nut 4
13 400420 Pan - Seat 2010 (f/Seat Belt)
14 400321 Seat - Michigan V5300 w/Suspension 1
15
15A
400423
400425
Mat - Pan Floor XC 74 All
Mat - Pan Floor XC 66 Gas, Propane, CNG
1
1
16 B-304 Bolt - 1/4-20X3/4 CARR FT Gr.5 Zinc 2
18
18A
400239
400249
Pan - Floor 74” Xcaliber
Pan - Floor 66” Xcaliber
1
1
20 B-109 3/8”-16x1-1/4” Bolt 2
21 400242 Guage Panel 1
REF PART# DESCRIPTION Qty
22 W-104 3/8” Flat Washer 4
23 500053 Accessory Plug 1
24 W-125 3/8” Nylon Washer 2
25 N-107 3/8”-16 Nyloc Nut 2
26 500037 Hourmeter 1
27 B-346 Bolt - 1/4-20X3/4 FH CARR Gr.5 Zinc 4
28 400242 Stainless Steel Front Panel 1
29 68239 Volt Meter 1
30 500016 PTO Switch 1
31 C-123 Clip - Christmas Tree 3/4 OAL 8
32 N-102 1/4”-20 Whiz Flange Nut 6
33 500017 Ignition Switch 1
33A 500018 Key 1
34 400246 Floor Pan Hinge 2
35 400190 Aluminum Propane Tank 2
36 400198 Propane Cylinder Bracket LR 1
36A 400197 Propane Cylinder Bracket LF 1
36B 400199 Propane Cylinder Bracket RR 1
36C 400196 Propane Cylinder Bracket RF 1
37 N-108 3/8”-16 Whiz Nut 24
38 B-137 3/8”-16 X 3/4” Bolt 12
39 W-104 3/8” Flat Washer 8
40 400194 Tank Bracket Mounting Bracket 2
41 B-206 3/8”-16 Square U-Bolt 1-3/8”W X 2”L 2
42 B-204 3/8”-16 Square U-Bolt 1-3/8”W X 3”L 4
43 400195 Tank Bracket Riser 2
44 20224 #13 Hair Pin Clip 2
45 P-115 3/8” x 1” Clevis Pin 2
