Dixie Chopper XCALIBER 2011 - Page 37

34
CNG BODY
REF PART# DESCRIPTION Qty
1 400401 Wrapper - Fender LH CNG 1
2 400402 Wrapper - Fender RH CNG 1
3 B-103 1/4”-20x1/2” Stainless Bolt 21
4 W-153 1/4” Stainless Flat Washer 29
5 N-101 1/4”-20 Stainless Whiz Flange Nut 2
6 B-209 1/4”-20X3/4” Stainless Bolt 8
7 B-105 5/16”-18x1.75” Bolt 2
8 W-113 5/16” Flat Washer 6
9 400247 Floor Pan Hinge Bracket 2
10 W-118 5/16”x1.5” Fender Washer 4
11 N-152S Nutsert - 1/4”-20, Flng, Znc (.027-.165) 18
12 N-103-W 5/16”-18 Whiz Flange Nut 4
13 400420 Pan - Seat 2010 (f/Seat Belt)
14 400321 Seat - Michigan V5300 w/Suspension 1
15 400425 Mat - Pan Floor XC 66 Gas, Propane, CNG 1
16 400354 Cover - Tank CNG 2
17 W-106 3/8” Fender Washer 2
18 400249 Pan - Floor 66” Xcaliber 1
19 B-104 5/16”-18x3/4” Carriage Bolt 2
20 B-109 3/8”-16x1-1/4” Bolt 2
21 400448 Assembly - Panel Guage CNG 1
22 W-104 3/8” Flat Washer 4
23 500053 Accessory Plug 1
24 W-125 3/8” Nylon Washer 2
25 N-107 3/8”-16 Nyloc Nut 2
26 500037 Hourmeter 1
27 B-346 Bolt - 1/4-20X3/4 FH CARR Gr.5 Zinc 4
28 400241 Panel - Front 74” 1
29 68239 Volt Meter 1
30 500016 PTO Switch 1
REF PART# DESCRIPTION Qty
31 C-123 Clip - Christmas Tree 3/4 OAL 8
32 N-102 1/4”-20 Whiz Flange Nut 6
33 500017 Ignition Switch 1
33A 500018 Key 1
34 400246 Floor Pan Hinge 2
35 600181 Tank - 13.9x035 w/HDWR NGV2 2
36 600182 Kit - Bracket Tank 13.9 3/4 Strap 2
37 N-108 3/8”-16 Whiz Nut 20
38 B-137 3/8”-16 X 3/4” Bolt 12
39 W-104 3/8” Flat Washer 8
40 400404 Mount - Tank CNG 2
41 B-206 3/8”-16 Square U-Bolt 1-3/8”W X 2”L 2
42 B-204 3/8”-16 Square U-Bolt 1-3/8”W X 3”L 4
43 400195 Tank Bracket Riser 2
44 20224 #13 Hair Pin Clip 2
45 P-115 3/8” x 1” Clevis Pin 2
46 400353 Cover - Tank Front CNG 2
47 400352 Cover - Tank Rear CNG 2
48 400399 Cap - Fender LH CNG 1
49 400400 Cap - Fender RH CNG 1
50 B-304 Bolt - 1/4-20X3/4 CARR FT Gr.5 Zinc 2
51 400436 Bracket - Guard Valve Tank Right CNG 1
52 400429 Guard - Valve Tank Left CNG 1
53 400435 Bracket - Guard Valve Tank Left CNG 1
