PROGRAMMING P SERIES
Page 28 of 100
“ANGL” - CUSTOM ANGLE SETTING ROUTINE
If Custom package type is selected “ANGL” is displayed. Press select button 1 to exit without setting angles,
or select button 4 to enter angle setting routine.
“1” is displayed for product position 1. Select buttons 2 and 3 will scroll up or down through the product depth
set for that column in the “SDEP” menu. IF “SDEP” ISN’T SET BEFORE SETTING A CUSTOM
PACKAGE TYPE, THE DEPTH WILL DEFAULT TO THE DEPTH FOR THE LAST PACKAGE TYPE.
Press select button 4 at the position prompt and “Hxxx” will be displayed with the
xxx flashing, this is the hold angle for the product position last displayed
Press select button 2 or 3 to scroll through the hold angle setting up or down (0 – 359). Press select button 4
to accept the displayed angle.
“Vxxx” will be displayed, this is the vend angle for the last product position displayed.
Press select button 2 or 3 to scroll the vend angle setting up or down (0 – 359). Press select button 4 to
accept the displayed angle.
Press select button 1 after the angles have been set for all the product positions.
COMMON PACKAGE SETTING INSTRUCTIONS RESUME HERE
“SAVE” will be displayed.
Press select button 1 to keep the current package type and “XX #” will be displayed.
Press select button 4 to save the package type selected and “PRM#“ will be displayed, where # is the
column to prime.
Press select button 1 to bypass the prime operation and return to the “XX #” display.
Press select button 4 to prime the indicated column. “PRM” will be displayed while the column is being
primed.
“XX #” will be displayed.
Press select button 1 to return to "PACG".
Press select button 2 to scroll to "RTN
".
"RTN" - RETURN TO SALES MODE
Press select button 4 will exit Service Mode and return to Sales Mode.
