PROGRAMMING P SERIES
Page 9 of 100
PROGRAMMING MENU
"EROR" - ERROR ROUTINE
This function allows you to enter the error readout routine. “EROR” will appear when you press the service button on
the control board. Press select button 4, if there have been no errors since the last reset, the display will read
"NONE". If one or more errors have occurred, the display will show the first error code that occurred.
The following are error codes that may be displayed and detailed information accessed: NONE, VEND, CTRL, SEL,
STS, CHAR, BUAL, CRDR, S-D, and RFRG.
Press select button 2 or 3 to scroll through any error codes that are present.
Important: If there is only one problem, that will be the only error code shown when you enter the error code
sub-menus.
With an error code showing on the display, press select button 4 to access detailed information.
With an error code showing on the display, press and hold select button 4 for 2 seconds, will clear the error.
Press select button 1 to return to "EROR".
"VEND" - Vend Mechanism Summary Errors
Press select button 4 and the display will show one of the following:
- "CJ#", where # is the column number detected jammed.
- “CS”, chute sensor failure.
- “HS”, home sense error.
Press select button 1 will return to "VEND" if all vend mech errors have not been cleared.
If all vend mech errors have been cleared the next error mode will be displayed, or "NONE" if there
are no errors.
Press select button 1 will return to "EROR".
"CTRL" - Control System Summary Errors
Press select button 4 and the display will show one of the following:
- "DS", indicating a door switch in the open position for more than 1 hour.
- "RAM", indicating the check sum for service mode settings memory has been corrupted.
- "ACLO", indicating AC supply to the machine has fallen more than 15% below normal line
voltage for more than 30 seconds.
- "SF", indicating a peripheral has introduced a scaling factor that is incompatible with current
setting.
Press select button 1 will return to "CTRL" if all control system errors have not been cleared.
If all control system errors have been cleared the next error code will be displayed, or "NONE" if
there are no errors.
Press select button 1 will return to "EROR".
"SEL" - Select Switch Summary Errors
Press select button 4 and the display will show "SL##", indicating a select switch has been active for
more than 15 seconds while in normal (sales) mode.
Press select button 1 will return to "SEL" if all select switch errors have not been cleared.
If all select switch errors have been cleared the next error code will be displayed or "NONE" if there
are no errors.
Press select button 1 will return to "EROR".
"STS" - Space To Sales Summary Errors
Press select button 4 and the display will show "UA##", indicating a column not assigned to a select
button.
Press select button 1 will return to "STS" if all space-to-sales errors have not been cleared.
If all space-to-sales errors have been cleared the next error code will be displayed, or "NONE" if
there are no errors.
Press select button 1 will return to "EROR".
