dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
64
©
2022 DJI All Rights Reserved.
5. GNSS Positioning Status: displays the number of searched satellites. RTK is only
displayed after the RTK module is installed. When the RTK service is not enabled, the
RTK icon is gray. When the RTK data is converged, the RTK icon will turn white. Tap the
GNSS positioning status icon to view the RTK mode and GNSS positioning information.
6. Signal Strength: includes the video and control signal quality. Three green dots indicate
strong signals, two yellow dots for medium signal strength, and one red dot for poor
signal quality. If the signal is lost, it displays a disconnected icon in red.
7. Intelligent Flight Battery Level: displays the battery level of the aircraft. Tap to view
battery level, voltage, and temperature.
8. Settings: tap to open the Settings menu to set the parameters of each module.
a.
Flight Control System Settings: includes flight mode switch, Home Point, return to
home altitude, maximum altitude, distance limit, sensor status, out-of-control action,
coordinated turn, and GNSS.
b.
Sensing System Settings: includes obstacle sensing switch, vision positioning
switch, and precision landing switch.
c.
Remote Controller Settings: includes stick mode, customizable button settings,
and remote controller calibration and linking.
d.
Video Transmission Settings: includes work frequency, channel mode, and video
output type.
e.
Intelligent Flight Battery Settings: includes battery information, smart return-
to-home, low battery warning thresholds, and number of days required for self-
discharge.
f.
Gimbal Settings: only appears when RTK module is mounted. Include gimbal pitch
settings, and gimbal auto calibration.
g.
RTK Settings: includes the RTK positioning function, RTK service type, and their
corresponding settings and status displays.
h.
General Settings: includes map selection, track display, unit setting, and lights
setting.

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
