DKS 1834 PC Programmable - Flush Mount Surface Mounting Kit Installation

1834-065-B-10-14
13
13.5”
12”
2.625”
Bottom View
Side ViewFront View
1.3.2 Flush Mount Surface Mounting Kit Dimensions and Installation
The Flush mount unit (See page 11 for
flush mount enclosure dimensions) can
be mounted ON a wall or pilaster and NOT
IN the wall by using the optional flush
mount surface mounting kit (P/N 1814-
152). This is useful when cutting a large
hole into a wall or pilaster would be very
difficult (marble or granite for example)
.The flush mount surface mounting kit is a
trim ring that fits around the flush mount
enclosure. The enclosure and trim ring get
installed directly on the wall using
appropriate hardware (not included) after
running all necessary conduit to the
enclosure. Be sure the unit is mounted
securely and is not subject to vibration
from closing doors or gates
Examples of some
small holes in the
wall that may be
needed, depending
on how you choose
to run the wiring.
1”
.375”
Trim Ring
Flush Mount
Enclosure
Knock-outs
Mounting Screws
(Not supplied
)
Wall
Trim Ring
1.125” Dia
1.5”3” 3” 3”
1.125” Sq
1.5”
.875”
1.125”
.875”
1”
Conduit run
to junction box
Conduit
sweep
run
Mount On a Surface
