DKS 1834 PC Programmable - Rotary-Dial 9 Relay Activation

1834-065-B-10-14
29
These steps will program the tone open numbers for Relays 1 and 2. You will need to enter a four-digit number (see chart
below) to set the relay functions. If a function is not desired, enter # in place of a number.
Factory setting is: Relay 0 = ####, Relay 1 = 9876, Relay 2 = 5432.
3.3.3 Tone Open Numbers
This programming sequence sets which relay(s) will activate when the switch input (main terminals #4 and #6) is activated on
the telephone entry system. The system can be programmed so that only one relay will activate, or both relays will activate. TIP:
The relay that you designate as the primary relay should be programmed to activate from the postal switch input.
Factory setting = 010 (only relay 1 activates)
3.3.4 Switch Input Relay(s) Activation
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to set Relay 1, OR (beep) to set Relay 2 tone numbers.
3. Enter the four-digit tone open number code, then press (beep).
(Example: If you want a relay to have a momentary activation function only, and you want that relay to momentary activate
when the number 9 is pressed, enter 9 # # #. If a function is not desired, enter # in place of a number. Do not duplicate tone
open numbers, Example: don’t set relay 1 and 2 tone-open numbers both to 9.)
4. Repeat steps 2 and 3 to set other relay tone open numbers.
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
5
5
OPER
OPER
0
0
JKL
JKL
1
1
SP
SP
2
2
ABC
ABC
0
0
OPER
OPER
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the three-digit (1's or 0's only) postal relay code, then press (beep).
Three-digit positions: 1st digit position - Always Set to “0”, 2nd digit position - Relay 1, 3rd digit position - Relay 2.
To activate a relay - enter a 1 in the second or third digit position.
To NOT activate a relay - enter a 0 in the second or third digit position.
Example: entering 010 will cause only relay 1 to activate. Entering 011 will cause both relays to activate.
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
0
0
TUV
TUV
5
5
OPER
OPER
0
0
OPER
OPER
1st Digit
2nd Digit
3rd Digit
4th Digit
Momentary activation. Relay will activate for the programmed strike time (3.3.1).
Relay hold. Relay will activate and remain activated until commanded to release.
Relay release. Deactivates the relay hold command.
Relay hold 1-hour. Relay will activate for 1-hour and then will automatically deactivate itself.
4-Digit Tone Open Number Code Function
Note: Residents will only be able to activate the Momentary activation when using the entry system.
