DKS 1834 PC Programmable - Programming the Instruction Message

1834-065-B-10-14
33
The instruction message scrolls across the screen from right to left when the system is not in use and follows the user
message programmed in 3.4.2. The instruction message can be a maximum of 52 characters (spaces count as a character)
and is entered into the system memory in three blocks. The first two blocks contain 20 characters while the third block contains
12 characters. The example below shows how the sample instruction message was divided into three blocks and programmed
into the system. Use the blank table to organize your own message. Only upper case letters, numbers and spaces can be
programmed from the system keypad.
Factory Default Instruction Message: Push A-Z To Find Name Enter Code Or Push Call
After organizing the instruction message in the table above, follow the instructions below to enter the message into the system.
After each desired letter, number or space is displayed on the directory, remember to press
*
to enter that character. Spaces
count as a character and must be entered into memory as a character. After a complete block of characters (including spaces)
has been entered, press
*
to enter the block, then start the next block.
Note: The factory default message was programmed from a PC, therefore upper and lower case letters are displayed.
Example: PUSH A OR Z BUTTON TO FIND NAME ENTER CODE OR PUSH CALL
Block 1
Block 2
Block 3
12345678 9 101112131415161718 19 20
PUSH A OR Z TO F I ND
NAME ENTER CODE OR P
Block 1
Block 2
Block 3
12345678 9 101112131415161718 19 20
1. Press and enter your four-digit MASTER CODE (beep).
The LCD display will read: BLOCK 1.
2. Enter the characters into block 1 (refer to 3.4.1 for reference). Remember to press (beep) after each character.
3. After the last character in block 1 has been entered, press (beep) to enter the entire block.
The LCD display will read: BLOCK 2.
4. Enter the characters into block 2. Remember to press (beep) after each character.
5. After the last character in block 2 has been entered, press (beep) to enter the entire block.
The LCD display will read: BLOCK 3.
6. Enter the characters into block 3. Remember to press (beep) after each character.
7. After the last character in block 3 has been entered, press (beep) to enter the entire block.
8. Press (beep) to enter all three blocks into the system memory.
9. Press together to end this programming sequence (beeeeeep).
10. The new instruction message will begin to scroll across the screen.
?
?
?
?
?
?
?
?
