1834-065-B-10-14
25
1. Press and enter your four-digit MASTER CODE (beep).
The LCD display will read: 10 AAC=0 255 AAC=1
2. Enter (beep) for 10 area codes OR enter (beep) for 255 area codes.
The display will read: ERASE MEM? 1=Y 0=N. (Choosing 1 WILL ERASE the memory and WILL evoke the area code choice.
Choosing 0 WILL NOT ERASE memory and WILL NOT evoke the choice).
3. Enter either (beeeeeep) to set the change OR (beeeeeep) to cancel the change.
This programming step sets the system to allow either “up to 10” or “up to 255” alternate area codes (AAC) to be programmed
into the system.
Factory setting = 1 (255 area codes)
3.2.2 Number of Area Codes Allowed
?
OPER
MNO
OPER
OPER
SP
SP
This feature is ONLY used when the telephone entry system is interfaced with a DoorKing 1816 or 1820 Telephone Intercom
system under certain special applications. This CALL-UP feature provides special programming that will allow the system to
call the phone number of a CO (Central Office) line connected to these systems. Once the 1816 or 1820 answers the call, the
system will automatically send out DTMF tones that will activate the CALL-UP feature in the 1816 or 1820 system, and then
send the four digit directory code to the resident selected by the visitor. This allows visitors to contact tenants in the building
that do not have CO phone service through the telephone entry system. Refer to the 1816 / 1820 Installation Manual, and check
with your DoorKing representative on the special applications that this feature is used for.
Factory setting = OFF (DO NOT turn ON unless interfacing with a 1816 or 1820)
3.2.3 Call-up Operation when Interfacing with DoorKing 1816 or 1820 Systems
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter (beep) to turn the call-up feature OFF.
Enter (beep) to turn the call-up feature ON. Special applications ONLY.
3. Press together to end this programming sequence (beeeeeep).
TUV
PQRS
OPER
SP
OPER
The following programming sequence turns the “Tone Open” sound either On or Off (when the relays activate). This feature is
available on Rev K boards or higher. See 3.3.3 for information about “Tone Open” numbers feature.
Factory setting = 1 (tone ON)
3.2.4 “Tone Open” Sound On or Off
1. Press and enter your four-digit MASTER CODE (beep).
The LCD display will read: BEEP RLY OP? 0=N 1=Y
2. Enter for YES - tone will sound or for NO - tone will not sound, then press (beep).
3. Press together to end this programming sequence (beeeeeep).
JKL
SP
SP
OPER
OPER
CAUTION:
When changing an existing 1834 “Area codes allowed” from 255 to 10, ALL existing
programmed memory will be erased but the programmed screen display messages, Section 3.4.
