3.6 Programming Four-Digit Entry Codes
Four-digit entry codes are entered ONLY on the Telephone Entry System Keypad preceded by “ # ” to allow the resident access.
Each entry code that you enter must be assigned to a directory code that you select (that was programmed in section 3.5.2).
Only ONE entry code can be programmed for each directory code. You cannot duplicate entry codes.
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the entry code will be assigned to (1, 2, 3 or 4 digits, section
3.5.1), then press (beep).
3. Choose and enter a four-digit entry code, press (beep).
4. Repeat steps 2 and 3 to enter additional entry codes. (You cannot duplicate entry codes)
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
2
2
ABC
ABC
0
0
OPER
OPER
0
0
OPER
OPER
3.6.1 Programming Four-Digit Entry Codes
Four-digit entry codes can be made to activate relay 1 or relay 2 or both relays by programming HI and LOW ranges for each
relay. Ranges between relays may overlap, which will cause more than one relay to activate if this is desired. For example, if the
low boundary for relay 1 is 2000, and the hi boundary is 3000, and the low boundary for relay 2 is 2000 and the hi boundary is
4000, then entry codes between 2000 and 3000 will activate both relays, and entry codes between 3001 and 4000 will only
activate relay 2.
3.6.3 Entry Code Ranges
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to set relay 1, or (beep) to set relay 2 boundary.
3. Enter the four-digit LOW boundary, then press (beep).
4. Enter the four-digit HI boundary, then press (beep).
5. Repeat steps 2, 3, and 4 to set the other relay boundaries.
6. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
2
2
ABC
ABC
1
1
SP
SP
0
0
OPER
OPER
1
1
SP
SP
2
2
ABC
ABC
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the desired entry code has been assigned to (1, 2, 3 or 4 digits,
section 3.5.1), then press (beep).
3. Enter , then press (beep).
4. Repeat steps 2 and 3 to delete additional desired entry codes.
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
2
2
ABC
ABC
0
0
OPER
OPER
0
0
OPER
OPER
3.6.2 Delete Entry Codes
