22
DMM Technology Corp.
DYN4 AC Servo Drive Instruction Manual
REV. ZM7-A10A
CT1
Single Phase Input:
Component Part
Recommended Current Rating
DYN4-L01 DYN4-H01 DYN4-T01
MCCB Molded case circuit breaker 10A 20A 30A
NF2 Main Noise Filter
5A
FN2030-6-06
10A
FN2030-10-06
15A
FN2030-16-06
LR1 AC Line Reactor (optional) 5A 10A 15A
MC1 Magnetic contactor 5A 10A 15A
F1 Logic Fuse 1A
NF1 Logic Noise Filter 1A Schaffner FN2030-1-06
A
C
B
T2
R1
R2
T
R
S
L1
L2
T4
PE
PE
Servo Motor
Power
Regenerative
Resistor
Main Circuit Power
Supply
Control Logic
Power Supply
DYN4 Servo Drive Servo Motor
JP3
A
C
B
Encoder
S
R S
F1
F1
NF1
FG
MCCB
T3
MC1
ESTOP
ON
OFF
External regenerative
resistor
MC1
NF2
LR1
