3-7
EN
3.3.3 All Helms Active screen
The All Helms Active screen (also called the Run screen) will be displayed
under normal operating conditions after the startup warning has been
acknowledged. The screen shows engine RPM, rudder angle, and legends
for the Display and Menu buttons.
MULTI
ENGINE
SINGLE
ENGINE
Figure 3-4. All Helms Active screens.
3.3.4 Steering maintenance screen
The Steering Maintenance screen allows user access to actuator calibration
and move functions. We recommend that you use these functions only under
the direction of a Dometic technical support representative.
Calibration is required if you used the emergency manual override procedure.
See section 6.3.2 for calibration instructions.
The move function is described in section 6.3.5.
