APPENDIX B
B.1 Bolt torque specifications
These are the recommended maximum torque values for reusable dry
bolts. Bolts should be torqued to this value +0% - 20%. For lubricated
bolts, multiply the dry bolt torque values by 0.75.
2-56 2.5 (.282) 2.0 (.226)
2-64 3.0 (.338) 2.5 (.282)
3-48 3.9 (.440) 3.2 (.361)
3-56 4.4 (.497) 3.6 (.407)
4-40 5.2 (.587) 4.3 (.486)
4-48 6.6 (.740) 5.4 (.61 0)
5-40 7.7 (.869) 6.3 (.71 2)
5-44 9.4 (1 .06) 7.7 (.869)
6-32 9.6 (1 .08) 4.9 (.554)
6-40 1 2.0 (1.35) 9.9 (1 .1 2)
8-32 20.0 (2.25) 1 6.0 (1 .81)
8-36 22.0 (2.48) 1 8.0 (2.03)
1 0-24 23.0 (2.59) 1 9.0 (2.14)
1 0-32 32.0 (3.61) 26.0 (2.94)
1/4"-20 75.0 (8.47) 62.0 (7.01 )
1/4"-28 94.0 (1 0.6) 77.0 (8.70)
5/1 6"-1 8 1 32.0 (1 4.91 ) 1 07.0 (1
2.10)
5/1 6"-24 1 42.0 (1 6.04) 1 1 6.0 (1 3.1 1 )
3/8"-1 6 236.0 (26.66) 1 92.0 (21 .71)
3/8"-24 259.0 (29.20) 21 2.0 (23.97)
7/1 6"-1 4 31.0 (42.00) 26.0 (35.25)
7/1 6"-20 33.0 (44.74) 27.0 (36.61 )
1 /2"-1 3 43.0 (58.30) 35.0 (47.45)
1 /2"-20 45.0 (61 .01 ) 37.0 (50.1 7)
9/1 6"-1 2 57.0 (77.28) 47.0 (63.72)
9/1 6"-1 8 63.0 (85.42) 51.0 (69.1 5)
5/8"-1 1 93.0 (1 26.09) 76.0 (1 03.04)
5/8"-1 8 1 04.0 (1 41 .00) 85.0 (1 1 5.24)
3/4"-1 0 1 28.0 (1 73.55) 104.0 (1 41.00)
3/4"-1 6 1 24.0 (1 68.1 2) 1 02.0 (1 38.29)
7/8"-9 1 94.0 (236.03) 1 59.0 (21 5.58)
7/8"-1 4 1 93.0 (261 .67) 1 58.0 (21 4.22)
1"-8 287.0 (389.1 2) 235.0 (31 8.6
2)
1"-1 4 259.0 (351 .1 6) 212.0 (287.43)
Bolt Size BrassBolt Size 18-8SSBrass18-8SS BrassBolt Size 18-8SS
Bolt Size BrassBolt Size 18-8SSBrass18-8SS BrassBolt Size 18-8SS
Values are stated in: -lbs (N.m)
Values are stated in: in-lbs (N.m)
B.2 System specifications
Operating voltage 12V DC nominal
(9V min/16V max per SAE J1455)
Current draw, average 8A per actuator
Current draw, peak 40A per actuator
operating
Current draw, maximum 55A per actuator
Circuit breaker rating 60A per actuator (not supplied by
Dometic)
Number of wheel turns Variable from 3.5 to 8
Steering angle Up to 30° in each direction
