Dometic EA1300 - Bulkhead Fitting Template

A-11
EN
Figure A-6. Bulkhead Fitting Template.
A.3 Bulkhead fitting template
NOTICE!
If this template has been downloaded electronically or copied from
another document, please verify all template dimensions prior to cutting.
Print/copy reproductions may be scaled differently.
1.5" (34 mm) DIA.
3 x 3/16" PILOT HOLE
✁
