Limp Home Mode 1
This mode occurs when the system cannot steer any of the engines. The
CANtrak will instruct you to manually center the engines if necessary (see
section 4.3.2) and proceed to port immediately using shift and throttle
controls to steer the boat.
Limp Home Mode 2
This mode occurs when one of the steering actuators is not working. This
means that one engine in a twin system (or two in a triple or quad system)
cannot be steered. The CANtrak will instruct you to move the affected
engine away from the others (see section 4.3.2), tilt it out of the water, and
proceed to port immediately using the responsive engine(s).
Table 4-1. Limp home mode 1 and instructions.
Table 4-2. Limp home mode 2 and instructions.
Limp Home Mode 1 – No steering is available
Multiple Outboard Engines Single Outboard Engine
Steering is disabled.
1. Return to port using throttles
to steer.
2. If engine(s) require re-centering:
a) Put all engines in neutral.
b Use tool provided (3/8”
wrench).
c) Loosen clamp bolts on
BOTH ends of steering
actuator sha.
d) Rotate sha to reposition
steering.
e) Tighten sha clamp bracket
bolts.
Steering is disabled.
1. Drive towards port.
2. If engine requires re-centering:
a) Put engine in neutral.
b) Use tool provided (3/8”
wrench).
c) Loosen clamp bolts on
BOTH ends of steering
actuator sha.
d) Rotate sha to reposition
steering.
e) Tighten sha clamp bracket
bolts.
3. Seek assistance when possible.
Limp Home Mode 2 – One of two steering actuators is disabled
Affected engine steering is disabled.
1. Affected engine must be positioned fully away from others.
2. To move engine manually:
a) Put all engines in neutral.
b) Use tool provided (3/8” wrench).
c) Loosen clamp bolts on BOTH ends of steering actuator sha.
d) Rotate sha to reposition steering.
e) Tighten sha clamp bracket bolts.
3. Fully tilt affected engine.
4. Return to port on remaining engines.
