Figure 5-24. Multi-Engine, Dual Station, Option 2.
PORT ACTUATOR
STARBOARD ACTUATOR
STATION 1
STATION 2
WYE HARNESS
CM21702
EXTENSION HARNESS
CM20036, OR CM22401
PLUS CM 204XX
WYE HARNESS
CM21702
HARNESS
CM204XX
