6
EN
General information RV So Start Accessory
4.3 Component locations
This section shows the Dometic Brisk II, Penguin II,
Blizzard NXT, and FreshJet AC unit dimensions, the AC
shroud screw locations, and the inside component
views. It also shows the component views for the device.
uu
yy
ww
ee
qq
rr
tt
ii
1 Brisk II AC unit shroud dimensions
q
13.7 in. (349 mm)
u
Air flow clearance
area (shaded)
w
29.6 in. (751 mm)
e
27.6 in. (701 mm)
i
18.0 in. (457 mm)
clearance
r
Front of unit
t
Roof opening
y
Center line of unit
qq
ww
ee
oo
rr
tt
uu
uu
ii
yy
2 Penguin II AC unit shroud dimensions
q
10.0 in. (264 mm)
u
4.0 in. (102 mm)
clearance
w
40.5 in. (1029 mm)
e
29.0 in. (737 mm)
i
Air flow clearance
area (shaded)
r
Front of unit
t
Roof opening
o
12.0 in. (305 mm)
clearance
y
Center line of unit
