OP000507
2-17
Operating Controls
Gauges
Warning and Indicator Lights
IMPORTANT
All of gauge and warning lights (except for the turn
lights, high beam light, work light and transmission
cutoff light) turn "ON" for two seconds with a warning
buzzer sound when the starter switch is turned to the
"I" (ON) position.
If any light fails to turn "ON" at this time, check the
cause and replace.
Reference
Number
Description
1 Fuel Gauge
2 Speedometer
3 Hour Meter
4 Tachometer
5
Engine Coolant Temperature
Gauge
6
Transmission Oil Temperature
Gauge
7 Transmission Display
Reference
Number
Description
Reference
Number
Description
8 Preheat Indicator Light
9
Air Cleaner Clogged Warning
Light
10 Battery Warning Light
11
Left Turn and Hazard Warning
Light
12 High Beam Indicator Light
13
Right Turn and Hazard
Warning Light
14 Work Light Indicator Light
15
Brake Fluid Pressure Warning
Light
16
F/R (Forward/Reverse) Selector
Indicator Light
17 Parking Brake Indicator Light
18
Emergency Steering Indicator
Light (Optional)
19 Engine Warning Light
20 Not Used
21 Not Used
22 Mirror Heating Indicator Light
23 Reverse Fan Indicator Light
24
Electric Steering Select
Indicator Light (Optional)
Reference
Number
Description
To Next Page
