OP000507Operating Controls
2-22
11. Left Turn and Hazard Warning Light
This light blinks when left turn signal is turned "ON."
Both lights blink when warning lights are turned "ON."
NOTE: If left and right turn indicators blink together, or if
they blink faster than normal, a light bulb is not
operating or flasher solenoid is damaged.
12. High Beam Indicator Light
This indicator light will turn "ON," when the headlights
are turned to "HIGH BEAM."
13. Right Turn and Hazard Warning
Light
This light blinks when right turn signal is turned "ON."
Both lights blink when warning lights are turned "ON."
NOTE: If left and right turn indicators blink together, or if
they blink faster than normal, a light bulb is not
operating or flasher solenoid is damaged.
FG004173
Figure 37
Figure 38
HAOD394L
FG004174
Figure 39
