OP000507
2-23
Operating Controls
14. Work Light Indicator Light
This indicator light will turn "ON," when the front and/or
rear work lights are activated.
15. Brake Fluid Pressure Warning Light
This warning light will turn "ON," when pressure drops
in brake fluid circuit. When light turns "ON," an alarm
also sounds.
16. F/R (Forward/Reverse) Selector
Indicator Light (Optional)
This indicator light will turn "ON," when the 2nd gear
function is selected.
NOTE: See “F/R (Forward/Reverse) Travel Control
System (Option)” on page 3-16 for further
information.
Figure 40
2658A
Figure 41
HA0O2024
WARNING!
Never operate or travel machine when this light is
"ON" or when alarm is sounding. Always
investigate cause of the drop in brake fluid
pressure, and repair problem before operating or
traveling machine.
Figure 42
BSO0510L
F/R
