OP000507Operating Controls
2-24
17. Parking Brake Indicator Light
This indicator light will turn "ON," when the parking
brake is "APPLIED." If vehicle is moved while parking
brake is applied, a warning alarm will sound.
18. Emergency Steering Indicator Light
(Optional)
This indicator light will turn "ON," when the emergency
steering system is activated due to a hydraulic failure.
Immediately stop any operation, stop machine, "APPLY"
parking brake, and shut down engine.
NOTE: The light will also turn "ON" when the system is
being tested.
Figure 43
P
0717A
WARNING!
If vehicle is moved while this light is turned "ON,"
it could cause premature wear or damage the
brake.
Always "RELEASE" parking brake and make sure
this light is "OFF" before traveling machine.
Figure 44
AJO0450L
DANGER!
Emergency steering indicator light. If this light
turns "ON" while operating machine, discontinue
operation immediately. This light indicates that
there is a serve problem with the unit.
To Next Page
