G643 (E) Service Manual Chapter 3. Engine Mechanical System 34
Oil Pan
Tightning Specifications for Oil Pan
(1) ............................................................Oil Pan
(2) Torque for Plug....................... 45 N· m (33 lb· ft)
(4) Torque for ten bolts................. 25 N· m (18 lb· ft)
(5) Torque for two nuts................. 25 N· m (18 lb· ft)
Oil Pump
Tightening Specifications for Oil Pump to Main Bearing Cap Bolt
(1)...........................................................Oil Pump
(2) Torque for bolt ...................... 90 N· m (66 lb· ft)
Oil Filter
Tightening Specifications for Oil Filter
(1) Wipe clean the filter adapter in the area that the
new filter makes contact. Put clean engine oil on
the new filter gasket. Install filter until contack is
made the tighten 3/4 turn more.
(2) Torque for adapter is
................................54 ± 14 N·m (40 ± 10 lb·ft)
