G643 (E) Service Manual Chapter 3. Engine Mechanical System 42
UPPER ENGINE PARTS
ITEM # DESCRIPTION ITEM # DESCRIPTION
1 COVER, VALVE ROCKER ARM (RH) 56 MODULE, DIST. IGN. CONT. (PT OF 3)
COVER, VALVE ROCKER ARM (LH) 61 SHAFT, DISTRIBUTOR (PT OF 3)
2 CAP, OIL FILL 62 RETAINER, DIST. IGN P/U COIL
3 DISTRIBUTOR 63 BOLT, IGNITION COIL
4 BOLT, DISTRIBUTOR CLAMP 64 COIL, IGN. (INCL. BRKTS, COIL, SCREW & NUT)
5 CLAMP, DISTRIBUTOR 67 OUTLET, WATER
6 GASKET, DISTRIBUTOR 68 GASKET, WATER OUTLET
9 GROMMET, VALVE ROCKER ARM COVER 69 THERMOSTAT, ENGINE COOL
11 PLUG, INTAKE MANIFOLD VACUUM HOLE 72 SENSOR, ENGINE COOL TEMP
12 PLUG, SQ HD FILL & DRAIN 77 VALVE, PCV
13 BOLT, INTAKE MANIFOLD 78 GROMMET, PCV VALVE
14 MANIFOLD, INTAKE 81 CAP, DISTRIBUTOR (PT OF 3)
15 GASKET KIT, 95 GUIDE, VALVE LIFTER PUSH ROD
17 BOLT, VALVE ROCKER ARM COVER 96 BOLT, VALVE LIFTER GUIDE
19 NUT, VALVE ROCKER ARM 97 NIPPLE, HTR INL HOSE
21 ARM, VALVE ROCKER 99 HOSE, WATER PUMP INLET (INCL. CLAMPS)
22 GASKET, VALVE ROCKER 2A GASKET KIT, INTAKE MANIFOLD
23 BOLT, CYLINDER HEAD (LONG)
24 BOLT, CYLINDER HEAD (MEDIUM)
25 BOLT, CYLINDER HEAD (SHORT)
26 SPARK PLUG
28 VALVE, EXHAUST
29 VALVE, INTAKE
30 LIFTER, VALVE
32 ROD, VALVE PUSH
33 GASKET, CYLINDER HEAD
34 HEAD, CYLINDER
35 STUD, VALVE ROCKER ARM BALL
36 SEAL, INTAKE VALVE STEM OIL
37 SPRING, VALVE (W/O DAMPER)
39 SEAL, EXHAUST VALVE STEM OIL
41 KEY, VALVE STEM
42 CAP, VALVE SPRING
44 BOLT, VALVE LIFTER GUIDE
48 PIN, DIST. GEAR (PT OF 3)
49 GEAR, DIST. SHAFT (PT OF 3)
50 WASHER, DIST. SHAFT (PT OF 3)
51 WASHER, DIST. SHAFT THR (PT OF 3)
52 SHIELD, DIST. IGN. P/U COIL (PT OF 3)
53 COIL, DISTRIBUTOR PICK UP (PT OF 3)
54 OLE PIECE & PLATE, DISTRIBUTOR (PT OF 3)
55 BOLT, DISTR. IGNITION ICM (PT OF 3)
