Dr.coffee 产品维修手册 40
10.2.1.1 Disassemble water tank base
Step1 :First open the water tank cover as shown in the figure, remove the large water tank upwards, and then remove a fixing screw at the marked
position of the red circle;
Step 2: Hold the base and take out the tank base downward. Remove the tank base
★ Attention：
1、Handle gently during disassembly to prevent scratching！
1
2
3
5
4
6
