Dr.coffee F10 - Disassemble Rear Panel; Disassemble Side Panel

Rev 0.0
Dr.coffee 产品维修手册 42
10.2.1.3 Disassemble rear panel
Step1：(As shown in Figure 1) Push the rear cover up from the bottom up, and use a flat-blade screwdriver to push out the two buckles, then remove
the rear cover；
10.2.1.4 Disassemble side panel
Step1: First push the left side panel from bottom to top, then pull back the left side panel and remove it, remove the left side panel to complete.
Step 2:First push up the right side plate, then pull back the right side plate and remove, remove the right side plate complete.
★ Attention：
1、Handle gently during disassembly to prevent scratching!
3 2 1
1 2
1
2
3
