Dr.coffee F10 - Maintenance; Milk Frother Clean

Rev 0.0
Dr.coffee 产品维修手册 53
11 Maintenance
11.1 Milk frother clean
Step1：(Figure 1) remove the milk tube
Step2：(Figure 1) Use your fingers to pinch the buckles on both sides of the foamer, (as shown in Figure 2), remove the cover, and then (as shown in
Figure 3) forcefully remove the foamer.
Step3：Pull out the connector and silicone part in the foamer and rinse it under the tap.
Step4：Put the rinsed milk frothers back into the machine as shown in the figure and cover the coffee outlet cover.
★ Attention：
1、Please disassemble the machine after it has cooled down to prevent burns！
2、When installing the silicone device, carefully check that it is in place. Otherwise it may also cause no milk or milk foam
1
2
1
2
3
1
2 3
1
2
3
4
