Rev 0.0
Dr.coffee 产品维修手册 46
10.2.5 Disassemble brew motor group
Step1：First pull out the wiring plug.
Step2：Then unscrew the two fixing screws at the position marked by the red circle, and finally take the drive unit out and take out the motor complete.
★ Attention：
1、 Be careful during the disassembly process to prevent scratching your fingers！
2、 Unplug the coffee machine before doing this！
1
4
2
3
