Rev 0.0
Dr.coffee 产品维修手册 45
10.2.4 Disassemble switch valve
Step1：Use a small slotted screwdriver to press the buckle with the short arrow to indicate the position, and then push the split valve back to the fixed
slot.
Step2：Unplug the two wiring plugs by the arrow, unplug the hose and water pipe connected to the red circle, and finally take out the split valve and
remove the valve.
★ Attention：
1、 Unplug the coffee machine before doing this！
2、 Take a picture for record before disassembling.
1 2
按压此处卡扣
5
3
4
